The 159A miniature transducer is developed for force measurements which require a compact design. This model employs single-bending beam working principle, so it needs to be installed as reverse beam in order to function properly. Constructed of stainless steel for outstanding stability and reliability, the 159A is available in a wide range of 30N to 500N.
Capacity | Kg | 1/2/5/7/10/20/30/40 |
Sensitivity | mV/V | 1.5±0.2 |
Accuracy | %FS |
≤±0.05 |
Creep(15min) | %FS | ≤±0.02 |
Input Resistance | Ω | 350±5 |
Output Resistance | Ω | 350±5 |
Insulation Resistance | M Ω | ≥5000(100VDC) |
Zero Balance | %FS | ≤±1 |
Temperature Effects on Span | %FS/10℃ | ≤0.05 |
Temperature Effect on Zero | %FS/10℃ | ≤0.05 |
Rated Temperature Range | ℃ | -10~+60 |
Operating Temperature Range | ℃ | -20~+80 |
Proposed Excitation Voltage | V | 6~12 |
Allowed Excitation Voltage | V | 18 |
Safe Overload | %FS | 120 |
Ultimate Overload | %FS | 150 |
Protection | IP65 | |
Cable specification | mm | Ф1Electronic wiring |
Cable length | m | 0.4 |
Material | Stainless Steel |
