Strain Gauge Load Cell
>
100kg Strain Gauge Load Cell With Aluminum Alloy Material For B2B Applications

100kg Strain Gauge Load Cell With Aluminum Alloy Material For B2B Applications

Product Details:
Place of Origin: China
Brand Name: Ruijia
Model Number: RJ9810
Detail Information
Place of Origin:
China
Brand Name:
Ruijia
Model Number:
RJ9810
Protection Class:
IP65
Output Signal:
2mV/V
Capacity:
100kg
Output Resistance:
350Ω
Compensated Temperature:
-10℃-50℃
Accuracy:
0.03%
Input Resistance:
385Ω
Excitation Voltage:
5V
High Light:

High Light

High Light:

100kg Strain Gauge Load Cell

,

IP65 Strain Gauge Type Load Cell

,

Aluminum Alloy Strain Gauge Platform Scale

Trading Information
Price:
USD 15/piece
Payment Terms:
L/C, T/T
Product Description

Product Description:

Strain Gauge Load Cell is a precision measuring instrument, which is widely used in platform scale, elevator and other industrial weighing systems. It is made of high-quality aluminum alloy and has excellent electrical insulation, with an insulation resistance of greater than 5000MΩ. Its ultimate overload capacity is 200%, and its zero balance accuracy is ±1%. The loading cable is 1m long and can support a wide range of applications. It is an ideal choice for industrial weighing systems and provides high accuracy and reliability.



Applications:

The Ruijia RJ9810 Strain Gauge Load Cell is a highly reliable and accurate weighing sensor that is widely used in various fields, such as elevators, cranes, and industrial automation. It features a robust design with a protection class of IP67 and an operating temperature of 0℃-60℃. The load cell also offers a maximum output signal of 2mV/V and an input resistance of 385Ω. It is further equipped with a compensated temperature range of -10℃-50℃, making it suitable for applications in tough environments. The load cell is a perfect choice for users who are looking for an accurate and reliable weighing sensor.

Dimension:

100kg Strain Gauge Load Cell With Aluminum Alloy Material For B2B Applications 0

Parameters:

Capacityt0.1/0.2/0.25/0.5/1/2/5
SensitivitymV/V2.0±0.005 3.0±0.005
Accuracy%FS

≤±0.02

Creep(15min)%FS≤±0.02
Input ResistanceΩ375±10
Output ResistanceΩ350±5
Insulation ResistanceM Ω≥5000(100VDC)
Zero Balance%FS≤±1
Temperature Effects on Span%FS/10℃≤0.02
Temperature Effect on Zero%FS/10℃≤0.02
Rated Temperature Range-10~+60
Operating Temperature Range-35~+80
Proposed Excitation VoltageV6~12
Allowed Excitation VoltageV18
Safe Overload%FS150
Ultimate Overload%FS300
Protection IP65
Cable specificationmmФ5
Cable lengthm3
Material Alloy Steel




































Customization:

Customized Strain Gauge Load Cell
Product Attributes
  • Brand Name: Ruijia
  • Model Number: RJ9810
  • Place of Origin: China
  • Output Resistance: 350Ω
  • Input Resistance: 385Ω
  • Material: Aluminum Alloy
  • Operating Temperature: 0℃-60℃
  • Capacity: 100kg

We provide custom-made strain gauge load cells that are perfect for weighing sensors.
Our strain gauge load cells are made with high-quality materials such as aluminum alloy and have an output resistance of 350Ω and input resistance of 385Ω.
It has a capacity of 100kg and its operating temperature range is 0℃-60℃.
Our strain gauge load cells are made by Ruijia, a reliable manufacturer based in China.



Support and Services:

Strain Gauge Load Cell Technical Support and Service
At ABC Company, we strive to provide the highest level of technical support and service for our Strain Gauge Load Cell products. Our team of experienced engineers and technicians are available to answer any questions you may have about our products, ensuring that you have the best possible experience with our products.
We offer a comprehensive range of technical support services, including:

  • On-site technical support
  • Remote technical support
  • Online technical support
  • Troubleshooting and diagnostic services
  • Software and firmware updates
  • Repair and maintenance services

If you have any questions or need assistance with our Strain Gauge Load Cell products, please contact our technical support team at support@abc.com.



Packing and Shipping:

Strain Gauge Load Cell Packaging and Shipping:

  • Securely package the load cell in foam or other cushioning material.
  • Ensure the load cell is supported in the center of the package.
  • Place the package in a cardboard box for shipping.
  • Securely tape the box shut.
  • Label the box with the appropriate shipping information.


FAQ:

Q1: What is the brand name of the Strain Gauge Load Cell?
A1: The brand name of the Strain Gauge Load Cell is Ruijia.
Q2: What is the model number of the Strain Gauge Load Cell?
A2: The model number of the Strain Gauge Load Cell is RJ9810.
Q3: Where is the Strain Gauge Load Cell made?
A3: The Strain Gauge Load Cell is made in China.
Q4: What are the applications of Strain Gauge Load Cell?
A4: Strain Gauge Load Cells can be used for force measurement, force calibration, force testing, and weighing applications.
Q5: What are the features of Strain Gauge Load Cell?
A5: Strain Gauge Load Cells are typically highly accurate, durable, and reliable. They are also usually compact and cost-effective.
