| Place of Origin: | china |
|---|---|
| Brand Name: | ruijia |
| Model Number: | RJ-6915 |
| Minimum Order Quantity: | 1pc |
| Price: | USD 6~11 |
| Packaging Details: | Standard export packaging |
| Delivery Time: | Within 2-4 Weeks |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 10000 Piece/Pieces per Month |
| Theory: | Resistance Sensor | Capacity: | 800kg |
|---|---|---|---|
| Sensitivity: | 2.0±0.05 MV/V | Accuracy: | ≤±0.05 |
| Input Resistance: | 1000±10 Ω | Output Resistance: | 1000±10 Ω |
| Rated Temperature Range: | -10~60 ℃ | Operating Temperature Range: | -20~+80 ℃ |
| Cable Specification: | Ф5 | Materail: | Aluminum Alloy |
| High Light: | 800kg Strain Gauge Load Cell,Elevator Weighing System Lift Sensor,USB Interface Strain Gauge Load Cell |
||
Elevator weighing controller system (elevator weighing system) plays an important role in the operation of elevators. The weighing controller consists of two parts, one part is the controller part and the other part is the load cell part. The load cell converts the weight signal into electric signal through the transmission cable to the controller part, which carries out calculation and processing to complete the weighing of the elevator.
When the weight in the elevator car changes, the controller can output multiple relay contact signals and 0~10mA current signal or 0~10V or -10V~+10V voltage signal as needed. When the elevator is overloaded, the controller will issue sound and light alarm to provide accurate data for the weighing and starting of the elevator.
| Capacity | Kg | 800 |
| Sensitivity | mV/V | 2.0±0.05 |
| Accuracy | ≤±0.05 | |
| Creep(15min) | %FS | ≤±0.02 |
| Input Resistance | Ω | 1000±10 |
| Output Resistance | Ω | 1000±10 |
| Insulation Resistance | M Ω | ≥5000(100VDC) |
| Zero Balance | %FS | ≤±1 |
| Temperature Effects on Span | %FS/10℃ | ≤0.02 |
| Temperature Effect on Zero | %FS/10℃ | ≤0.02 |
| Rated Temperature Range | ℃ | -10～+60 |
| Operating Temperature Range | ℃ | -20～+80 |
| Proposed Excitation Voltage | V | 6～12 |
| Allowed Excitation Voltage | V | 18 |
| Safe Overload | %FS | 120 |
| Ultimate Overload | %FS | 150 |
| Protection | IP65 | |
| Cable specification | mm | Ф5 |
| Cable length | m | 1.4 |
| Material | Aluminum Alloy |
