Strain Gauge Load Cell
>
Double Ended Shear Beam 5ton Rope Tension Load Cell For Electronic Crane Scales

Double Ended Shear Beam 5ton Rope Tension Load Cell For Electronic Crane Scales

Product Details:
Place of Origin: Shannxi, China
Brand Name: Ruijia
Model Number: RJ-9910
Detail Information
Place of Origin:
Shannxi, China
Brand Name:
Ruijia
Model Number:
RJ-9910
Usage:
Weighing
Theory:
Strain Gauge Deformation
Capacity:
1~5 T
Sensitivity:
1.0±0.1 MV/V
Accuracy:
≤±0.02
Creep(5min):
±0.1 %FS
Input Resistance:
380±20 Ω
Output Resistance:
350±5 Ω
Temperature Effects On Span:
±0.1 %FS/10℃
Temperature Effect On Zero:
±0.1 %FS/10℃
Material:
Alloy Steel
High Light:

High Light

High Light:

5ton Rope Tension Load Cell

,

Electronic Crane Scales Tension Load Cell

,

Double Ended Shear Beam Load Cell

Trading Information
Minimum Order Quantity:
1pc
Price:
USD 30/piece
Packaging Details:
Standard export packaging
Delivery Time:
Within 2-4 Weeks
Payment Terms:
T/T, L/C
Supply Ability:
10000 Piece/Pieces per Month
Product Description

Double Ended Shear Beam 5ton Rope Tension Load Cell For Electronic Crane Scales 0



Product Description



  1. The elastic element is a monolithic hollow section circular shaft with compact structure and simple geometric shape, which is easy to process with high dimensional and form accuracy.

  2. The hollow section has a strong resistance to torsion and bending, and the stress at the neutral axis of the shaft pin is the highest.

  3. When the hollow section shaft pin is subjected to vertical and horizontal bending, the section with zero bending moment is in the same section.

  4. When designing a larger capacity shaft pin sensor, the central hole is also larger, and the double-shear type electro-negative strain gauge can be pasted inside the hole, i.e., well protected and the vacuum-filled inert gas sealing process can be implemented.

  5. Easy to assemble with related load-bearing parts and convenient to use.




Dimension


Double Ended Shear Beam 5ton Rope Tension Load Cell For Electronic Crane Scales 1



Technical Parameter:



Capacity t

1~5

Sensitivity mV/V

1.0±0.1

Accuracy %FS

±0.5

Creep(15min) %FS ±0.1
Input Resistance Ω 380±20
Output Resistance Ω 350±5
Insulation Resistance M Ω ≥5000(100VDC)
Zero Balance %FS ±2
Temperature Effects on Span %FS/10℃ ±0.1
Temperature Effect on Zero %FS/10℃ ±0.1
Rated Temperature Range -10~+60
Operating Temperature Range -20~+80
Proposed Excitation Voltage V 5~12
Allowed Excitation Voltage V 18
Safe Overload %FS 150
Ultimate Overload %FS 200
Protection   IP65
Cable specification mm Ф5
Cable length m 3m
Material   Alloy Steel
