Shear Beam Load Cell 0.5-50T Alloy Steel Truck Scale Sensor

Product Details:

Place of Origin:	CHINA
Brand Name:	RJ
Certification:	CE/ROSE
Model Number:	RJ

Detail Information

Place of Origin:

CHINA

Brand Name:

Certification:

CE/ROSE

Model Number:

Capacity:

0.5t-50Ton

Material:

Alloy Steel

Accessory:

Force Bearing Foot

Precision:

0.03% F.S

Creep:

0.02%RO/30min

Insulation Resistance:

5000 MΩ(50V)

Highlight:

High Light

Highlight:

Shear Beam Load Cell 50T capacity

Alloy Steel Truck Scale Sensor

Shear Beam Load Cell for weighing

Trading Information

Minimum Order Quantity:

Price:

$20-150

Packaging Details:

Carton or wooden crate

Delivery Time:

5-8 work days

Payment Terms:

L/C,D/A,D/P,T/T,Western Union

Supply Ability:

2000PC/month

Product Description

Truck Scale Shear Beam Load Cell 1 Ton 2 Ton 5 Ton 10 Ton 20 T 30 Ton Weight Sensor

Shear Beam Load Cell 0.5-50T Alloy Steel Truck Scale Sensor 0

Features:

Rated load: 0.5-50T

Precision: C2 / C3

Safe overload:150%

Ultimate overload: 200%

Material: Alloy steel

Apply to: Truck scale or silo / tank / bin weighing system

Application	Floor scale
Model	RJ
Capacity	0.5t, 1t, 2t, 3t, 5t, 8t, 10t, 20t, 30t, 50t
rated output	2.0±0.004mV/V
Accuracy class	C2 C3
maximum number of verification intervals	2000 Nmax 3000 Nmax
Minimum loadcell cerification intervals	Emax/5000Vmin Emax7500 Vmin
Combined error	≤±0.030 % RO ≤±0.020 % RO
Creep	0.02%RO/30min
Temp. effect on sensitivity	0.0016 %RO/℃ 0.0014 %RO/℃
Temp.effect on zero	0.005%RO/℃ 0.002%RO/℃
Zero balance	±1.0 %RO
Input resistance	365±10ohm 1050 ±10 ohm (optional)
Output resistance	350±3 ohm 1000 ±5 ohm (optional)
insulation resistance	5000 MΩ(50V)
Recommended excitation voltage	8-15V
Compensated temperature range	-10-+40℃
operating temperature range	-35-+80 ℃
safe overload	120 %RO
Ultimate overload	200%RO
loadcell material	alloy steel -IP67 stainless steel
Connecting cable	0.5~3Ton: Φ5.7x3.5 m / 5t~8t: Φ5.7 x 8 m / 10t~50t: Φ6.3x13 m
Method of connecting wire	Red- input+, black- Input-. Green- Output+, White- output -

Shear Beam Load Cell 0.5-50T Alloy Steel Truck Scale Sensor 1

Wiring & Force bearing diagram

Shear Beam Load Cell 0.5-50T Alloy Steel Truck Scale Sensor 2

Wiring & Force bearing diagram

Shear Beam Load Cell 0.5-50T Alloy Steel Truck Scale Sensor 3

Packing & Transport

Shear Beam Load Cell 0.5-50T Alloy Steel Truck Scale Sensor 4
