Parameters | Values |
Capacity | 0.22/0.55/1.1/1.76/2.2/4.4t |
Rated output | 1.94±1%mV/V |
Zero Balance | ±2%mV/V |
Creep(30min) | ≤0.0166%F.S. |
Non-linearity | ≤0.017%F.S. |
Hysteresis | ≤0.017%F.S. |
Repeatability | ≤0.017%F.S. |
Input Resistance | 390±3Ω |
Output Resistance | 350±5Ω |
Temp.effect on output
|
0.014%F.S./10 °C
|
Temp.effect on zero
|
0.012%F.S./10 °C |
Insulation resistance | ≥5000MΩ/100V(DC) |
Recommended excitation | 5~12V |
Maximum excitation | 15V |
Compensated Temp Range | -10~60 °C |
Operating Temp Range | -20~80 °C |
Safe Load Limit |
150%F.S.
|
Breaking Load |
200%F.S.
|
Cable size
|
∅5.4x1.5m
|
Material
|
Stainless steel |
