| Specifications |
Technique |
| Capacity |
10,20,50,100,200,500kg |
| Accuracy class |
C3 |
| Rated output |
2.0±0.05mV/V |
| Zero balance |
±2%F.S. |
| Non-linearity |
0.018%F.S. |
| Hysteresis |
0.017%F.S. |
| Repeatability |
0.018%F.S. |
| Creep(30min) |
0.0166%F.S. |
| Temp.effect on output |
0.008%F.S./10ºC |
| Temp.effect on zero |
0.0125%F.S./10ºC |
| Input impedance |
390±5Ω |
| Output impedance |
350±5Ω |
| Insulation |
≥5000MΩ/100VDC |
| Recommended excitation |
5~15V |
| Maximum excitation |
20V |
| Compensated temp range |
-10~40ºC |
| Operation temp range |
-30~70ºC |
| Safe overload |
150%F.S. |
| Ultimate overload |
300%F.S. |
| Cable size |
Φ5.4×1500mm |
| Material |
Stainless Steel |
| IP Class |
IP68 |
