Load Cell Sensor
>
50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output

50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output

Product Details:
Place of Origin: CHINA
Brand Name: RJ
Certification: CE/ROSE
Model Number: RJ
Detail Information
Place of Origin:
CHINA
Brand Name:
RJ
Certification:
CE/ROSE
Model Number:
RJ
Output:
2.0vm/v
Capacity:
3~120kg
Rated Output:
2.0±0.2
Non-linearity:
0.03%FS
Hysteresis:
0.03%FS
Repeatability:
0.03%FS
Highlight:

High Light

Highlight:

50 ton load cell sensor

,

truck weighing load cell

,

2.0mv/v output load cell

Trading Information
Minimum Order Quantity:
1
Price:
$5-10
Packaging Details:
Carton or wooden crate
Delivery Time:
5-8 work days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union
Supply Ability:
2000PC/month
Product Description

Truck 50 Ton Weighing Scale Load Cell

50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output 0


Load cells are used in smart devices, smart vending cabinets, smart garbage bins, weight detection equipment, etc., and are easy to install and operate.

Specifications
Rated Output
mv/v
2.0±0.2
Non-linearity
%F.S
0.03%F.S
Hysteresis
%F.S
0.03
Repeatability
%F.S
0.03
Creep
%F.S/3min
0.03
Temp.effect on zero
%F.S/10℃
0.03%F.S
Temp.effect on span
%F.S/10℃
0.05%F.S
Zero balance
mv/v
±0.05
Input impedance
Ω
405±6
Output impedance
Ω
350±5
Insulation resistance
≥2000(100VDC)
Recommended excitation voltage
VDC
3~12
Allowed excitation voltage
VDC
3~12
Compensated temp.Range
-10℃~+40℃
Operating temp.Range
0℃~+40℃
Safe overload
%F.S
120
Ultimate Overload
%F.S
150
Connection
Excitation: Red:+ Black:-
Signal: Green:+ White:-

50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output 1
