Model | RJ501 | RJ502 | RJ04 |
Capacity | 0.3,0.5,1,1.5,2,3,4,5kg | 200,300,600g,1,1.5,3kg | 3,6,10,20,30,40kg |
Rated output | 1.0±10%mV/V(0.3,0.5kg)2.0±10%mV/V(1~5kg) | 1.0±20%mV/V | 2.0±10%mV/V |
Zero balance | ±0.02mV/V | ±0.05mV/V | ±0.02mV/V |
Creep(30min) | ≤0.0166%F.S. | ≤0.016%F.S. | ≤0.017%F.S. |
Non-linearity | ≤0.015%F.S. | ≤0.015%F.S. | ≤0.015%F.S. |
Hysteresis | ≤0.015%F.S. | ≤0.015%F.S. | ≤0.015%F.S. |
Repeatability | ≤0.015%F.S. | ≤0.015%F.S. | ≤0.015%F.S. |
Input resistance | 380±40Ω | 405±5Ω | 405±10Ω |
Output resistance | 380±40Ω | 350±3Ω | 350±5Ω |
Temp.effect on output | 0.017%F.S./10 C | 0.02%F.S./10 C | 0.02%F.S./10 C |
Temp.effect on zero | 0.02%F.S./10 C | 0.03%F.S./10 C | 0.02%F.S./10 C |
Insulation resistance | ≥5000MΩ/100V(DC) | ≥5000MΩ/100V(DC) | ≥5000MΩ/100V(DC) |
Recommended excitation | 5~15V | 5~15V | 5~15V |
Maximum excitation | 20V | 20V | 20V |
Compensated temp range | -10~40 C | -10~40 C | -10~40 C |
Operating temp range | -25~70 C | -10~50 C | -20~60 C |
Safe load limit | 150%F.S. | 150%F.S. | 150%F.S. |
Breaking load | 200%F.S. | 200%F.S. | 200%F.S. |
Cable size | ∅4x3000mm | ∅4x3000mm | ∅4x400mm |
Weight | 0.1kg | 0.1kg | 0.1kg |
Material | Aluminum Alloy | Aluminum alloy | Aluminum alloy |
Model | RJ506 | RJ507 |
Capacity | 50~1000kg | 100,200g |
Rated output | 2.0±20%mV/V | 0.9±0.1mV/V |
Zero balance | ±0.1mV/V | ±0.05mV/V |
Creep(30min) | ≤0.02%F.S. | ≤0.0166%F.S. |
Non-linearity | ≤0.017%F.S. | ≤0.015%F.S. |
Hysteresis | ≤0.017%F.S. | ≤0.015%F.S. |
Repeatability | ≤0.015%F.S. | ≤0.015%F.S. |
Input resistance | 405±15Ω | 405±20Ω |
Output resistance | 350±5Ω | 350±10Ω |
Temp.effect on output | 0.0175%F.S./10 C | 0.02%F.S./10 C |
Temp.effect on zero | 0.0177%F.S./10 C | 0.03%F.S./10 C |
Insulation resistance | ≥2GΩ/100V(DC) | ≥5000MΩ/100V(DC) |
Recommended excitation | 1~12V | 5~15V |
Maximum excitation | 15V | 20V |
Compensated temp range | -10~40 C | -10~40 C |
Operating temp range | -10~50 C | -10~50 C |
Safe load limit | 150%F.S. | 150%F.S. |
Breaking load | 200%F.S. | 200%F.S. |
Cable size | ∅6x1m | ∅4- 1x100mm |
Weight | 0.6kg | 0.1kg |
Material | Aluminum alloy | Aluminum alloy |
Company Information
Service standards: we are committed to provide a high quality and responsive service to all clients
The fastest reply: Please feel free to contact us if you have any questions. You will get a reply from the professional and experienced trade manager within 24 hours. If our trade manager is off line, please leave a message, and tell us the product model you need and your E-mail address.
Quality assurance: good quality is assured by advanced manufacturing technology. And all products are through strict test by our professional QC team before shipping.
Door to door service: We usually send the parcel by DHL, EMS and TNT etc. The tracking number will be sent to you after delivery. It usually takes 3--5 working days to reach from from our side to your side, which is very convenient for your business
OEM available
