30 Ton 50ton Analog Output Spoke Type Load Cell , Industrial weighing donut compression load cell

Basic Information
Place of Origin: China
Brand Name: ruijia
Model Number: RJ-8610
Minimum Order Quantity: 1pc
Price: USD25-80/pc
Packaging Details: Standard export packaging
Delivery Time: 2-4 weeks
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000 Piece/Pieces per Month
Detail Information
Usage: Pressure Sensor Capacity: 0.5-100T
Comprehensive Error (%F.S): ±0.05 Safe Overload (%F.S): 150
Excitation Voltage (V): 10(DC) Application: Truck Scales,hopper Scale And Other Weighing Devices
High Light:

compression type load cell

,

stainless steel load cell


Product Description



30 Ton 50ton Analog Output Spoke Type Load Cell , Industrial weighing donut compression load cell



Spoke Type Load Cell​ is the heart of electronic weighing apparatus. As the rapid development of sensor technology, electronic weighing apparatus have been widely used in many industrial areas. It is used in tank scales, hopper scales, hanging scales, vehicle scales, and other scales or control systems that require fast and accurate force measuring.



What is strength of Load cell?



1. Made of alloy steel or stainless steel

2. Suitable for belt weigher, hopper scale and other weighing devices

3. Good steel performance and high accuracy



What is specifications of Load cell?



Specification:

Range (T): 0.5-100

Comprehensive error (%F.S): ±0.05

Insulation resistance (MΩ): ≥5000

Rated output (mV/ V): 2.0

Temp. effect on span (%F.S/10℃): ±0.05

Creep (%F.S/30min): ±0.05

Temp. effect on zero (%F.S/10℃): ±0.05

Zero balance (%F.S): ±1.0

Operation temp. range (℃): -20~+65

Input resistance (Ω): 380±10 or 750±15

Excitation voltage (V): 10 (DC)

Output resistance (Ω): 350±3 or 700±5

Safe overload (%F.S): 150

Wiring information:

Red: Input (+)

White: Output (-)

Black: Input (-)

Green: Output (+)



What is Dimension of Load cell?



GSS406 Industrial weighing donut 1 ton 100 ton load cell sensor

Range

Size (mm)

T

φA

φB

φC

φF

MD

H

E

0.5-7

105

88.9

6.5

32

M16x1.5

37

34

10-25

125

101.6

8.5

39

M32x1.5

52

48

30-50

145

116.8

10.5

50

M40x1.5

58

54

60-100

205

162

12.5

80

M60x2

85

78







Range (T)

Size(mm)

φ

L1

L

M

SR

0.5-7

31

13

28

M16*1.5

80

10-25

38

24

51

M32*1.5

120

30-50

50

32

62

M40*1.5

200

60-100

80

42

80

M60*2

280



What is Product Details of Load cell?

GSS406 Industrial weighing donut 1 ton 100 ton load cell sensor



What is application of Load cell?



30 Ton 50ton Analog Output Spoke Type Load Cell , Industrial weighing donut compression load cell 2





FAQ



Q:What are the applications of spoke type load cell?

A: Belt scale, batching scale, cement mixing plant, reaction kettle weighing system, tank weighing system, silo scale, etc.



Q:What is the raw material?

A: Alloy steel



Q: What is the load range?

A: 1-470T



Q: What is the accuracy/precision?

A: C2 0.03% and C3 0.02%



Q: How to install?

A: Install them under the tank, then connect all the load cells with junction box and connect junction box with controller indicator or display indicator
